250m TCS EMI RFI Shielding Gaskets 15mm Monel Wire Mesh

Name: 250m TCS EMI RFI Shielding Gaskets 15mm Monel Wire Mesh
Brand: Jovi
Price: 3.19 USD

Brand Name : Jovi

Model Number : 1-CF-12

Certification : CE

Place of Origin : China

MOQ : 200m

Price : USD 3.19-19.5 per M

Payment Terms : L/C, T/T, Western Union

Supply Ability : 28000m per month

Delivery Time : 10-15 working days

Packaging Details : Carton or wooden case

Product Name : Shielding Material EMI Shielding Gasket Monel Knitted Wire Mesh

Material : TCS ，Monel

Feature : With or without adhesive

Application of EMI shielded gasket : RF shielded door , RF cage/room

Length : 100m / roll or 250m / roll

Width : 15mm / 20mm / 30mm / customized

Contact Now

Shielding Material EMI Shielding Gasket Monel Knitted Wire Mesh

Knitted wire meshes are produced from a single continuous filament

and produce a very high level of EMI Shielding Performance evenly compressed between two metallic contact surfaces.

Our Meshes are available in four basic wire types - Monel, Aluminium, TCS ( Tinned Copper-clad Steel), and Stainless Steel.

Each has its own specific characteristic but TCS is generally regarded as the most suitable for EMP Shielding.

Specifications and Material

Monel - BS3075 - NA13	(0.11 mm diameter)
Aiuminium5056 - AMS 4182	(0.13 mm diameter)
TCS - ASTM B520	(0.11 mm diameter)
Stainless Steel - Alloy 304	(0.13 mm diameter)

Performance

Frequency			Al	TCS	S/Steel
10 KHz	H	45	40	60	40
100 KHz	H	49	45	65	44
1MHz	H	60	60	85	58
1MHz	E	125	125	125	125
10 MHz	E	120	120	120	120
100 MHz	E	100	100	108	100
400 MHz	P	98	95	99	94
1GHz	P	85	76	78	76
10 GHz	P	80	65	62	60

250m TCS EMI RFI Shielding Gaskets 15mm Monel Wire Mesh
